PCF8574 I2C LCD Demo

Share on facebook
Share on twitter
Share on linkedin
Share on email
Share on print
Table of Contents
Description

The PCF8574 I2C LCD uses just two lines to interface: SDA (serial data) and SCL (serial clock), plus 5VDC and Vss. This LCD, which is available from Parallax with yellow or blue backlight, was extensively demonstrated in the Propeller 2 Live Forum: Spin2 for Beginners Series with JonnyMac. The YouTube video demonstrating the code is linked under Additional Resources.

Three programs are included in this Quick Byte:

The 02_jm_lcd_pcf8574_demo.spin2 and jm_lcd_pcf8574.spin objects are a complete, documented examples with all of the methods to display text and decimals, position the cursor, control the backlight, etc.
