Propeller Multicore Concept
P1 and P2 Hub RAM Interfaces
The Propeller microcontrollers’ eight processing cogs (cores) each operate independently or cooperatively, communicating through shared resources at-will. Each cog has direct access to its internal memory and shares equal access to all I/O pins and system resources. This nimble design affords flexible processing power and easy adaption to numerous uses, freeing developers from task-specific ICs while reducing part counts and design-to-production time.
Processing is swiftly performed in isolation within individual cogs. Shared resources are accessed through a time-sharing “Hub” mechanism, conceptually demonstrated by these animations. See the table below them for a feature comparison.
Propeller Microcontroller Feature Comparisons
|Feature/Specification||Propeller 1 (P8X32A)||Propeller 2 (P2X8C4M64P)|
|Power||3.3 V||1.8 V Core, 3.3 V I/O|
|Internal Oscillator||~12 MHz or ~20 kHz||20+ MHz or ~20 kHz|
|Nominal System Speed||80 MHz||180 MHz @105 °C|
|Internal Execution Speed||0 to 160 MIPS (20 MIPS/cog)||0 to 720 MIPS (90 MIPS/cog)|
|Hub Access Speed||20 MB/s/cog @ 80 MHz||720 MB/s/cog @ 180 MHz (using FIFO)|
|Main RAM||32 KB||512 KB|
|Cog RAM||512 longs||512 longs Cog RAM + 512 longs Lookup RAM|
|Inter-Cog Communication||Main RAM or External I/O||Main RAM, Lookup RAM, Attention Signal, or External I/O|
|I/O Type||Digital||Digital and analog with smart circuits|
|Languages||Spin, PASM, BASIC, C/C++, Blockly||Spin2, PASM2, MicroPython, Forth, BASIC, C/C++|
